| Model | Vin (V) | Iin (A) | PF | Vout(V) | Iout(mA) | Pout(W) | Ta(℃) | Type TL / Tc(℃) | Eff |
|---|---|---|---|---|---|---|---|---|---|
| SLC 18-65 120-277 W P | 120-277 | 0.09-0.25 | 0.95 | 30-50 | 500 | 25 | -20~55 | 85/58 | 88% |
| SLC 35-I700 120-277 W P | 120-277 | 0.12-0.35 | 0.95 | 30-50 | 700 | 35 | -20~55 | 85/58 | 88% |
| SLC 40-I1050 120-277 W P | 120-277 | 0.14-0.40 | 0.95 | 21-38 | 1050 | 40 | -20~55 | 85/58 | 88% |
| SLC 50-1400 120-277 W P | 120-277 | 0.17-0.50 | 0.95 | 21-36 | 1400 | 50 | -20~55 | 85/58 | 88% |
SLC 18-65 W P Series
-
-
Input Voltage：120-277VAC
Input frequency is 50Hz-60Hz
High Power Factor,Low THD
Auto Recovery
Short circuit protection
Over-current protection
UL/cUL,Type TL,UL Class 2
|
