Shanghai Arcata Electronic Inc.

SL 40-65 Series

  • line Voltage:120~277V ac 50/60Hz
    Constant Current Output
    High Power Factor, Low THD
    Auto Recovery
    Open Circuit Protection
    Short Circuit Protection
    Output Current Tolerance:±5%
    UL/cUL,Type TL,UL Class 2

Model Vin (V) Iin (A) PF Vout(V) Iout(mA) Pout(W) Ta(℃) Type TL / Tc(℃) Eff
SL 40-I1050120-277W 120-277 0.15-0.38 0.95 20-38 1050 40 -20~55 85/58 87%
SL 50-I1050120-277W 120-277 0.2-0.48 0.95 30-52 1050 50 -20~55 85/58 87%
SL 50-I1400120-277W 120-277 0.2-0.48 0.95 21-36 1400 50 -20~55 85/58 87%
SLC 63-I1400120-277WP 120-277 0.25-0.59 0.95 20-45 1400 63 -20~50 90/71 89%
SLC 65-I1500 120-277WP 120-277 0.26-0.6 0.95 20-43 1500 65 -20~50 90/71 89%
SLC 60-I1200 120-277WP 120-277 0.23-0.56 0.95 20-50 1200 60 -20~50 90/71 89%
SLC XX-IYYY120-277WP 120-277 0.25-0.64 0.95 20-53 700-1700 35-65 -20~50 90/71 87%





  Standards
  UL8750
  IEC61000-3-2
  FCC Part 15 Class A, ANSI C63.4:2009



Safety


  No PCB's
  UL
  Sound Rated: A

  Dimensions:
  Overall Length(L): 6.00''±0.1''
  Width(W): 1.80''±0.1''
  Height(H): 1.10''±0.1''
  Mounting(M): 5.69''±0.1''
